11 Seat Golf Cart
Electric vehicle product description1. Motor: US ADC brands2. Controller: US CurTis12663. Battery:Trojan4. Stable quality, little noise, anti-fatigue and long durability5. There is oil seal which can bear high temperature, therefore it can prevent the transaxle from oil leakage Electric systemcontr......
Send Inquiry
Product Description
Electric vehicle product description
1. Motor: US ADC brands
2. Controller: US CurTis1266
3. Battery:Trojan
4. Stable quality, little noise, anti-fatigue and long durability
5. There is oil seal which can bear high temperature, therefore it can prevent the transaxle from oil leakage
1. Motor: US ADC brands
2. Controller: US CurTis1266
3. Battery:Trojan
4. Stable quality, little noise, anti-fatigue and long durability
5. There is oil seal which can bear high temperature, therefore it can prevent the transaxle from oil leakage
Electric system | controller | 1268/400A | ||
| battery | Trojan battery 8V 6 units | |||
| motor | KDS48V/3.7KW motor | |||
| charger | Computer Intelligent input 220V/110V ourput 48V 20A | |||
| Charging time | Less than 12 hours discharging rate 80% | |||
| Body configuration | Glass | PC glass | Sun Roof | ABS Vacuum forming |
| seat | leather | Floor | Autiskid rubber floor | |
| Rear mirror | Handoperated, both side | Steering | Dual automotive-style strut and self-adjust rack-and pinion steering | |
| DC/Light/Signal | 48V/12V-300W Front light turning light rear light horn Buzzer | |||
| Body | PP Vacuum forming | |||
| Dash Board | PP Vacuum forming Voltage Indicator 48V Switch Head Lights Switch - Indicators Right/Left key switch Switch Forward/Reverse | |||
| Braking system | Rear drum brake+compound pedal brake | |||
| Front axle and suspension | Independent suspension helical spring +cylinder hydraulic shock absorption | |||
| Rear axle and suspension | Integral type transaxle, gear ratio 12.31: 1, semi-independent transaxle, spring, cylinder hydraulic shock absorption | |||
| Tire diameter | 452mm | |||
| Parameter | Length*width*height | 4200*1200*1900mm | ||
| Loading passenger | 11 | |||
| Max speed km/h | 22km/h | |||
| Mileage /km | 70_ 80kmflat road | |||
| Max climbing ability | 15% | |||
| Mini turning radiumm | 5m | |||
| Mini ground clearance | 110mm | |||
| Wheel base | Front 930/back 1010mm | |||
| Braking distance | 5.5M | |||
1). 13 years experience in Producing the golf cart and golf cart parts
2). America Curtis programmable controller
3). 6 years Made in China gold supplier
4). 5 stars supplier of Global Sources
5). North America ,European, Australia and Asia are the main market.
