Chinese 2 Seaters Electric Car on Sale
Chinese 2 Seaters Electric Car on SaleMain Components:1)ADC Motor2)Curtis Controller3)Sunup Transaxle4)Trojan Battery Electric systemcontroller1268/400Abatterytrojan battery 6V 8unitsmotor48V/4KW motorchargerComputer Intelligent input 220......
Send Inquiry
Product Description
Chinese 2 Seaters Electric Car on Sale
Main Components:
1)ADC Motor
2)Curtis Controller
3)Sunup Transaxle
4)Trojan Battery
Main Components:
1)ADC Motor
2)Curtis Controller
3)Sunup Transaxle
4)Trojan Battery
| Electric system | controller | 1268/400A | |||
| battery | trojan battery 6V 8units | ||||
| motor | 48V/4KW motor | ||||
| charger | Computer Intelligent input 220V/110V ourput 48V 20A | ||||
| Charging time | Less than 12 hours discharging rate 80% | ||||
| Body configuration | Glass | Sandwich glass | Sun Roof | Fiber glass | |
| seat | leather | Floor | Autiskid rubber floor | ||
| Rear mirror | Handoperated,both side | Steering | Dual automotive-style strut and self-adjust rack-and pinion steering | ||
| DC/Light/Signal | 48V/12V-300W Front light turning light fog light rear light horn Buzzer | ||||
| Body | Fiber glass | ||||
| Dash Board | Fiberglass dash board Voltage Indicator 48V Switch Head Lights Switch - Indicators Right/Left key switch Switch - Forward/Reverse | ||||
| Braking system | Front disc and rear dram,four-wheel hydraulic brake+hand brake | ||||
| Front axle and suspension | Independent suspension helical spring +cylinder hydraulic shock absorption | ||||
| Rear axle and suspension | Integral type transaxle,gear ratio 12.49:1,semi-independent transaxle,spring,cylinder hydraulic shock absorption | ||||
| Tire diameter | 535mm | ||||
| Parameter | Length*width*height | 4100*1483*1900mm | |||
| Container size | 2615*1430*550 | ||||
| Loading passenger | 2 | ||||
| Max speed km/h | 25km/h | ||||
| Mileage /km | 70_90km flat road | ||||
| Container size KG | 1000KG | ||||
| Max climbing ability | 15% | ||||
| Mini turning radium m | 4.04m | ||||
| Mini ground clearance | 120mm | ||||
| Wheel base | Front 1180/back 1200mm | ||||
| Braking distance | 3.5M | ||||
| Electric system | controller | 1268/400A | |||
| battery | US2000 batter 6V 8units | ||||
| motor | 48V/4KW motor | ||||
| charger | Computer Intelligent input 220V/110V ourput 48V 20A | ||||
| Charging time | Less than 12 hours discharging rate 80% | ||||
| Body configuration | Glass | Sandwich glass | Sun Roof | Fiber glass | |
| seat | leather | Floor | Autiskid rubber floor | ||
| Rear mirror | Handoperated,both side | Steering | Dual automotive-style strut and self-adjust rack-and pinion steering | ||
| DC/Light/Signal | 48V/12V-300W Front light turning lightfog light rear light horn Buzzer | ||||
| Body | Fiber glass | ||||
| Dash Board | Fiberglass dash board Voltage Indicator 48V Switch Head Lights Switch - Indicators Right/Left key switch Switch - Forward/Reverse | ||||
| Braking system | Front disc and rear dram,four-wheel hydraulic brake+hand brake | ||||
| Front axle and suspension | Independent suspension helical spring +cylinder hydraulic shock absorption | ||||
| Rear axle and suspension | Integral type transaxle,gear ratio 12.49:1,semi-independent transaxle,spring,cylinder hydraulic shock absorption | ||||
| Tire diameter | 535mm | ||||
| Parameter | Length*width*height | 4100*1483*1900mm | |||
| Container size | 2615*1430*550 | ||||
| Loading passenger | 2 | ||||
| Max speed km/h | 25km/h | ||||
| Mileage /km | 70_90km flat road | ||||
| Container size(KG) | 1000KG | ||||
| Max climbing ability | 15% | ||||
| Mini turning radium m | 4.04m | ||||
| Mini ground clearance | 120mm | ||||
| Wheel base | Front 1180/back 1200mm | ||||
| Braking distance | 3.5M | ||||
